‘PIE’ Brand Digital Flange Wear Gauge Model FWG-1 (D) for BG Electric Loco with Accuracy ±0.01 mm with Calibration Certificate.
Wheel Wear Measuring Gauges
Wheel Wear Measuring Gauges
Rolling stock maintenance tools are an assembly of two wheels that are fixed to the axle and do not have independent movement. There are flanges of the inner side which act as guides for the wheels to play on railway tracks and act against derailment. Locomotive wheels undergo heavy Linear and transverse forces subjecting them to wear and tear. As part of normal wear and tear, flange defects tend to crop up over a period of time e.g., Thin flange, Deep flange, Sharp flange, Less radius at root of flange etc.
The wheel profile gauge for BG Electric Locomotives can be used for measurement in the pit or on the rails. The electronic models can either be used for manual measurement or transfer the data through USB. Interface and have an accuracy of ±0.01 mm with Calibration Certificate.
DIGITAL ROOT WEAR GAUGE MODEL RWG-1 (D)
‘PIE’ Brand Digital Root Wear Gauge for BG Electric Loco Model RWG-1 (D) with Accuracy ±0.01 mm with Calibration Certificate.
DIGITAL TREAD WEAR GAUGE MODEL TG-1 (D)
Digital Tread Wear Gauge of robust and water resistant (IP 67) design, main frame made from hardened and ground stainless steel, hardened measuring pointers. Make ‘PIE’ Model TG-1 (D).
DIGITAL WHEEL WEAR GAUGE MODEL WWG-1 (D)
‘PIE’ make Digital Wheel Wear Gauge Model WWG-1 (D) for B.G. Locos, capable of measuring main wheel wear parameters with a resolution of 0.1 mm.
FLANGE WEAR GAUGE MODEL FWG-1 (SKDL-4445)
‘PIE’ Brand Flange wear gauge Model FWG-1– Precisely made Flange wear gauge (B.G) for thick profile as per RDSO Drawing no. SKDL–4445 made of hardened steel complete in case. The gauge measures Flange wear of wheel.
MINI TYRE DEFECT GAUGE MODEL MTDG-1
‘PIE’ Brand Pocket Size Mini Tyre Defect Gauge (Model-MTDG-1) is made of 3 mm thick hardened steel plate.
Multipurpose Wheel Wear Measuring Gauge/qR Gauge Model WWMG-V
‘PIE’ brand Multipurpose Wheel Wear Gauge/qR Gauge our Model WFMG-V suitable for measuring flange thickness, flange height and value of qR of flange.
P8 PROFILE GAUGE
‘PIE’ Make Adjustable Tyre Gauge for P8 Profile. Model ATG – P8 complete in case.
ROOT WEAR GAUGE MODEL RWG-1 (SKDL-4444)
‘PIE’ Brand Root wear gauge Model RWG-1 – Precisely made Root wear gauge (B.G) for thick profile as per RDSO Drawing no .SKDL–4444 made of hardened steel complete in case. The gauge measures Root wear of wheel.
TREAD WEAR MEASURING GAUGE MODEL TWG-1 (C&W)
‘PIE’ Brand Tread Wear Measuring Gauge Model TWG-1 (C&W) for carriage and wagon, made of alloy steel with hardened measuring pointers.
TREAD WEAR MEASURING GAUGE MODEL TWG-1 (EMU)
‘PIE’ Brand Tread Wear Measuring Gauge Model TWG-1 to solid wheel EMU’s for Tyred wheels, made of hard alloy steel with hardened measuring pointers.
TRED WEAR MEASURING GAUGE MODEL TWG-1 (BG Loco)
‘PIE’ Brand Tread wear measuring gauge Model TWG-1 (BG Loco) for thick/wear adopted profile combined for B.G. Locos, made of alloy steel with hardened measuring pointers.
TYRE DEFECT GAUGE MODEL TDG-1
‘PIE’ Brand Tyre Defect Gauge/Condemning Gauge Model TDG-1 as per Plate 38 Rule 2.8.4 of IRCA made of 3mm thick hard alloy steel plate.
